SPECIFICATIONS

Brand Name: Willsenton

Certification: CE

Channels: 2 (2.0)

Hign-concerned Chemical: None

Maximum Power Per Channel: 45W

Model Number: R8

Package: Yes

Parts: Adapter

WILLSENTON Model: R8

⚡RARE DEAL! Open Box Amplifier - Perfect Condition, US Buyers ONLY! ⚡

⚡RARE DEAL! Open Box Amplifier - Perfect Condition, US Buyers ONLY! ⚡

⚡RARE DEAL! Open Box Amplifier - Perfect Condition, US Buyers ONLY! ⚡

Version Note: Products may be shipped in different batches and are shipped randomly. Testing has shown no difference in core functionality or reliability between the new and old versions. All devices undergo the same rigorous testing to ensure full functionality.

All items guaranteed 100% BRAND NEW in the original edition Box.

ONE-YEAR WARRANTY !!!

Features:

• Pure hand-made, Point to point manual welding.

• Use a square power transformer specially developed for this machine.

• The output transformer uses two high quality wideband EI output transformers.

• The preamp stage uses one 6SN7 for power supply filtering.

• The voltage amplification stage and the push stage use two pairs of 6SL7 and 6SN7 tubes, respectively.

• The power amp stage uses KT88 tubes for class AB Push-pull power amplification.

• Triode and ultra-linear selection are available. The triode works in a soft, pure-and sleek sound, suitable for listening to vocals, strings and other types of music. Ultra-linear working mode, sound-tone open, unrestrained, good momentum, suitable for enjoying big scenes, big dynamics and other types of music.

• External independent BIAS-ADJ current display header. Adjustment and BIAS meter monitoring function keeps the best state of the power tube at all times.

• External KT88 tube selection function, easy to replace different types of tubes, adding endless fun.

• Infrared full-featured remote control.

• Use thick silver plated signal leads.

• With pure post-level function, it can be connected to independent preamplifier signal input.

• Power on mute delay function (about 30 seconds).

• Select Japanese ALPS high-end motor potentiometer.

• Easy-to-install plug-in tube cage cover.

Product parameters:

Product parameters:

FTC rated output power : 16W+16W triode (8Ω, 20HZ-20KHZ, THD 1%) (KT88)

: 30W+30W ultra-linear (8Ω, 20HZ-20KHZ, THD 1%) (KT88)

Output Power rating (not tested under the FTC standard): 23W+23W (RMS triode working state) (KT88)

Output Power rating (not tested under the FTC standard): 45W+45W (RMS ultra-linear working state) (KT88)

Overall frequency response: 12Hz-40KHz (±1.5dB)

Total harmonic distortion: 0.2% (1W/1kHz, rated output power less than 5%)

Signal-to-noise ratio: 91dB

Input sensitivity: 260Mv ((when be an Integrated amp), 560Mv (when be a Power amplifier) (EL34)

Input sensitivity: 320Mv (when be an Integrated amp), 700Mv (when be a Power amplifier) (KT88)

Input impedance: 100KΩ

Output impedance: 4Ω, 8Ω

Preamp stage power supply filtering Tube: 6SN7*1

Voltage amplifier stage Tube: 6SL7*2

Driver stage Tube: 6SN7*2

Power vacuum tube: KT88*4

Power supply voltage: AC 120V 60Hz/50Hz

3-14 business days to order)

Power consumption: 280W

Dimension: (W*H*D): 400*203*390 mm （16*8*15inch）

Net weight: 26kg（57LB）

Gross Weight: 30kg(66LB)

Working Condition: Temperature: 0℃～40℃ Moisture: 20%～80%

Storage Condition: Temperature: -20℃～70℃ Moisture: 20%～90%
